Toolkit: your class terminal, your data and your VM¶

Version 0.2.1 · draft · 2026-10-15 · class/demos/toolkit.md

The reference every demo uses. Lab 0 signs you in and opens a command line; this page has the rest: your class terminal on both sites, the commands that write and prove your data, your file in the VM, and the proof table. Each demo points at the section it needs.

T.1 Your class terminal, signed in on both sites¶

_{🎬 T.1 Your class terminal, signed in on both sites: a recording of this whole section, done in the console (placeholder until recorded: class/.images/toolkit-t-1-class-terminal-both-sites.mp4).}

Open it¶

Every command in these guides runs in your browser terminal: a shell inside your own pod, sql-client, opened from the OpenShift console. Nothing is installed on your computer. It has psql, the class commands (T.2), oc, virtctl and jq, and it already knows who you are and where your VM is. You have one on each site; use the one on site A unless a guide says otherwise.

In the site A console, open your project: Home → Projects → <your class ID> (or pick it in the Project list at the top of any page).
Go to Workloads → Pods, open the pod sql-client-…, and choose the Terminal tab.
Type ovedr and press Enter. It shows your class ID, your VM and its address, which site this terminal is on, and what is signed in yet.

📋 Copy and paste. The Terminal tab is a normal browser terminal: - Paste a command from these guides with right-click → Paste, or Ctrl+Shift+V (Windows/Linux) / ⌘V (Mac). The copy button on each command block in the class site copies it for you. - Copy output by selecting it with the mouse, then right-click → Copy (or Ctrl+Shift+C / ⌘C). Plain Ctrl+C stops the running command, as in any terminal. - Paste one block at a time and wait for the prompt. Most class commands are one short line you can also type.

[verify: paste and copy shortcuts in the 4.19 console terminal, per browser]

💡 The terminal keeps your sign-ins while the pod runs, even if you close the tab or the browser. If the pod is ever restarted, run dblogin and oclogin again. Leaving a long command running? Keep its tab open.

Sign its `oc` in, for both sites¶

With SSO, oc signs in with a token from the console, never a password. Do this once per site, in the same terminal:

In the site A console, open your name (top right) → Copy login command → Display Token. Copy the line that starts with oc login --token=….
In your terminal, type oclogin and a space, paste the line, and press Enter.
Repeat in the site B console: copy its login command and paste it after oclogin in the same terminal.

oclogin oc login --token=sha256~… --server=https://api.ocp-lz1.demo.lab-paragonmicro.com:6443   # ✓ site-a: signed in as …
oclogin oc login --token=sha256~… --server=https://api.ocp-lz2.demo.lab-paragonmicro.com:6443   # ✓ site-b: signed in as …

oclogin names each sign-in after its site, so every later command says which cluster it talks to (--context site-a / --context site-b), and it sets your namespace as the default. Tokens last 24 hours: if oc says Unauthorized, repeat the step for that site.

oc --context site-a whoami && oc --context site-b whoami   # both print your class ID
oc --context site-a get project "$VMNS"                    # yours, on site A …
oc --context site-b get project "$VMNS"                    # … and on site B
oc --context site-a auth can-i '*' '*' -n "$VMNS"          # yes: admin in your own namespace

What it already knows¶

⚠️ The landing zones change from booking to booking. The scheduler picks whichever zones are free, so your vSphere zone can be lz1, lz2 or lz3, and your two clusters any two of ocp-lz1, ocp-lz2, ocp-lz3, in any order (for example vSphere lz2 with site A ocp-lz3 and site B ocp-lz1). The examples in these guides use lz1 / ocp-lz1 / ocp-lz2. Always use your booking's values (the instructor gives them out), never the examples.

Value	Example
`ME`: your class ID	`student-03-0024-005`
`N`: vSphere landing zone number	`1` (→ `vcenter01`)
`A`: site A cluster	`ocp-lz1`
`B`: site B cluster	`ocp-lz2`

Your VM name and its vSphere address follow from your ID:

You are	VM (`$VM`)	Address on vSphere (`$VM_IP`)
`student-NN-…`	`win-pg-sNN` (e.g. `student-03` → `win-pg-s03`)	`10.101.<22+N>.<100+NN>` (e.g. `10.101.23.103`)
the instructor	`win-pg-i01` (the instructor's VM, in `vms/ovedr`)	`10.101.<22+N>.62`

[verify: BL-D10, per-student clones and their address plan]

You don't type these in. Your browser terminal (T.1) already holds all of them, and your VM's name and address, as $ME, $N, $A, $B, $VM, $VM_IP, $VMNS, $WINUSER, $VC and $DOMAIN. Type ovedr there to see them.

Your namespace, $VMNS. On both OpenShift clusters you have your own namespace (project), named exactly your class ID in lower case, for example student-03-0024-005. It matches your vCenter folder. You are admin there: full rights, scoped to that namespace only. Your migration plans land your VM there, and your VM's SQL Service ($VM-sql) lives there, and so does your browser terminal, pod sql-client (T.1). Instructors get their own namespace too (their class ID, where win-pg-i01 lands), are admin in every student namespace, and are cluster-admin on both clusters, so they can help with any student, storage or operator issue.

T.2 The data-integrity commands¶

_{🎬 T.2 The data-integrity commands: a recording of this whole section, done in the console (placeholder until recorded: class/.images/toolkit-t-2-data-integrity-commands.mp4).}

The database bcdr has two tables you will use:

Table	Written by	What it proves
`heartbeat`	a writer in the VM, every 5 s	the VM is alive. Gaps in it are outages.
`marks`	you, at every stage	your data survived every move, unchanged and in order

Each of your marks rows carries a SHA-256 hash of the previous row. If a row is lost, changed or reordered, ovedr_verify reports chain_ok = f and names the first broken row.

Your class commands (already in your terminal)¶

Command	What it does
`dblogin`	sign in to your VM's database as you (`student_NN`), with your class password. Once per pod
`mark <label> [note]`	inject one hash-chained row; note its `id`. Example: `mark d1-before`
`load <label> [rows]`	inject a burst of rows (default 100)
`verify`	read and prove your rows: `chain_ok = t`, and the fingerprint of all marks
`alive`	is your VM writing? `staleness` under 10 s = yes
`sql [psql options]`	`psql` to your VM's database, e.g. `sql -c "SELECT count(*) FROM marks"`
`where`	which site and node runs your VM right now
`tools`	after a migration: VMware Tools out, the virtio drivers and the QEMU guest agent in (your VM's own report)
`ovedr`	who and where you are, and what is signed in

They talk to your VM at its own address, $VM_IP, which it keeps on vSphere, site A and site B (the staged plans use a bridge network map). So they work from either site's terminal, before and after every move. If you ever move your VM onto the pod network yourself, T.4 shows how to point them at its new address (export PGHOST=…).

dblogin                          # Password for student_NN: your class password (it is not shown as you type)

ovedr_checksum fingerprints every mark in your VM's database. On your own VM that is your rows only. On the instructor's win-pg-i01 it covers everyone who marked it.

Try it now¶

alive                            # staleness under 10 s: your VM is writing
mark first-row                  # your first row: note its id and sha
verify                           # chain_ok = t, marks = 1

📸 toolkit-verify: the verify output with chain_ok = t.

✍️ Proof table, row 0 (at the start of Demo 1): your first mark's id, and the fingerprint from ovedr_checksum.

💡 Why a hash chain? A count can't tell you that row 7 was replaced, or that rows 7 and 8 swapped places. A chain can. A migration or a failover that loses, rewrites or reorders even one of your rows shows up here as chain_ok = f.

T.3 Your Windows VM, and your file in it¶

_{🎬 T.3 Your Windows VM, and your file in it: a recording of this whole section, done in the console (placeholder until recorded: class/.images/toolkit-t-3-windows-vm-file.mp4).}

Your VM runs Windows Server 2022 with PostgreSQL 16. The WAL (write-ahead log) is on L: (256 MB) and the data is on D: (1 GB).

While it is on vSphere: in vCenter, select your VM and choose Launch Web Console.
Once it is on OpenShift: in the console, go to Virtualization → VirtualMachines → your VM → Console.

Send Ctrl-Alt-Del from the console toolbar, then log in as .\<WINUSER> (for example .\student-03) with your class password [verify: BL-D08, student Windows accounts].

Your file in the VM¶

Open PowerShell in the VM and leave your mark on disk, not just in the database:

$f = "C:\Users\Public\ovedr\$env:USERNAME.txt"
New-Item -ItemType Directory -Force (Split-Path $f) | Out-Null
Add-Content $f "$(Get-Date -Format o)  first-row"
Get-Content $f

Every demo adds a line to this file at each stage. Its last step reads the file back on the target platform.

📸 toolkit-windows-touch: PowerShell showing Get-Content of your file.

T.4 (Optional) Give your VM a pod-network address on OpenShift¶

_{🎬 T.4 (Optional) Give your VM a pod-network address on OpenShift: a recording of this whole section, done in the console (placeholder until recorded: class/.images/toolkit-t-4-optional-pod-network-address.mp4).}

You usually skip this. Every class VM has its own static address (instructor .62, students .100+NN), and the staged migration plans use the bridge network map (ovedr-vcenter0<N>-net-bridge), which puts the migrated NIC on the same VLAN. So after a move your VM answers at the same $VM_IP as before, and every helper keeps working.

Do this step only when your VM landed on the pod network: a plan you built yourself with the pod map (ovedr-vcenter0<N>-net), or a site without the bridge. A Windows static address on a pod-network NIC answers nothing, so you swap it for a pod NIC that gets its address by DHCP, and then test over that address.

ℹ️ Demo-only, not a production pattern. Swapping the NIC is a lab workaround for a VM that landed on the pod network. In a real migration the VM keeps its own NIC, MAC and address (a bridge map onto the same VLAN, as the staged plans do, or a planned re-IP), and nobody swaps NICs. Proper per-VM addressing (DHCP on the lab VLANs) is on the backlog (BL-D12). Background: Virtual machine networking [verify link].

CTX is the site your VM is now on (site-a after demos 1-2, site-b after demo 3).

1. Stop the VM¶

CTX=site-a
virtctl --context "$CTX" -n "$VMNS" stop "$VM" 2>/dev/null \
  || oc --context "$CTX" -n "$VMNS" patch vm "$VM" --type merge -p '{"spec":{"runStrategy":"Halted"}}'
oc --context "$CTX" -n "$VMNS" get vm "$VM" -w            # Ctrl-C at Stopped

2. See the migrated interface(s)¶

oc --context "$CTX" -n "$VMNS" get vm "$VM" -o json \
  | jq -r '.spec.template.spec.domain.devices.interfaces as $i | .spec.template.spec.networks as $n
           | range(0; $i|length) as $k | "\($k)  \($i[$k].name)  mac=\($i[$k].macAddress // "-")  net=\($n | map(select(.name == $i[$k].name))[0] | (.pod // .multus) | tostring)"'

✍️ The index (0, 1, …) of the migrated NIC: ____

3. Set the migrated NIC's link down, and add a pod-network NIC¶

Console: VM → Configuration → Network → ⋮ on the migrated NIC → Set link down (or Delete), then Add network interface: network Pod networking, type Masquerade.

CLI:

IDX=0                                    # ← the index you wrote down
oc --context "$CTX" -n "$VMNS" patch vm "$VM" --type json -p "[
 {\"op\":\"add\",\"path\":\"/spec/template/spec/domain/devices/interfaces/$IDX/state\",\"value\":\"down\"},
 {\"op\":\"add\",\"path\":\"/spec/template/spec/domain/devices/interfaces/-\",
  \"value\":{\"name\":\"default\",\"masquerade\":{},\"model\":\"virtio\"}},
 {\"op\":\"add\",\"path\":\"/spec/template/spec/networks/-\",
  \"value\":{\"name\":\"default\",\"pod\":{}}}]"

[verify: interface state: down (link state) on OpenShift Virtualization 4.19]. If your cluster rejects state, remove the migrated NIC instead: oc --context "$CTX" -n "$VMNS" patch vm "$VM" --type json -p "[{\"op\":\"remove\",\"path\":\"/spec/template/spec/domain/devices/interfaces/$IDX\"}]", then remove the matching entry under /spec/template/spec/networks/ the same way.

If the migrated NIC is already named default on the pod network (the …-net map), it is the same kind of NIC and is already unique per VM. Skip step 3 and go to step 4.

4. Start the VM and confirm DHCP inside Windows¶

virtctl --context "$CTX" -n "$VMNS" start "$VM" 2>/dev/null \
  || oc --context "$CTX" -n "$VMNS" patch vm "$VM" --type merge -p '{"spec":{"runStrategy":"Always"}}'
oc --context "$CTX" -n "$VMNS" get vmi "$VM" -w           # Ctrl-C at Running

In the VM console (.\<WINUSER>):

Get-NetAdapter | Format-Table Name, Status, MacAddress, LinkSpeed
ipconfig /all | Select-String 'Description|Physical|DHCP Enabled|IPv4|Default Gateway'

✅ The new adapter shows DHCP Enabled: Yes, and an address from OpenShift's masquerade network (the guest side is 10.0.2.2 [verify]).

The old static IP was configured on the old adapter, so the new adapter starts clean on DHCP. If Windows has pinned the static IP to the new adapter, reset it: Set-NetIPInterface -InterfaceAlias '<new adapter>' -Dhcp Enabled; ipconfig /renew.

5. Read your VM's address, and use it for every test¶

The guest's address is private to the VM. From outside, your VM is reached at its pod IP:

export PGHOST=$(oc --context "$CTX" -n "$VMNS" get vmi "$VM" \
  -o jsonpath='{.status.interfaces[?(@.name=="default")].ipAddress}')
echo "PGHOST=$PGHOST"                    # your VM's own address on $CTX

The alternative is your VM's Service, Service/$VM-sql. It selects vm.kubevirt.io/name=$VM on port 5432, so it follows your VM whatever its IP: export PGHOST=$VM-sql.

6. Connection test¶

pg_isready -h "$PGHOST" -p 5432          # accepting connections
alive
mark own-address "ip=$PGHOST"
verify

✅ pg_isready answers accepting connections, the heartbeat is fresh, and chain_ok = t.

Windows has no SSH server by default, so the PostgreSQL connection above is the connection test. To work inside Windows, use the VM's Console tab in the OpenShift console.

📸 toolkit-own-address: ipconfig on the new adapter beside the PGHOST echo.

Proof table (carry it through every demo)¶

Row	Stage	Your last mark id	`chain_ok`	Fingerprint	Notes (outage, bytes, time)
0	first-row
